Square easy

Office solutions · LED

Square easy

https://www.arlistore.com/web/image/product.template/57/image_1920?unique=abc402e

Square easy is a 595x595 mm LED panel with state-of-the-art LED technology and LED source with 50,000 hours lifetime. Available in 3 power options, color temperatures 3000K/4000K with CRI 80+. Steel body with PMMA diffuser for optimal light distribution and DALI control option available. Fully compatible with existing lighting infrastructure. Ideal for offices, halls and commercial spaces. 5-year warranty.

Technical specifications

Light Source
LED
CCT
3000K, 4000K
CRI
80
Switching type
Non-dimmable , DALI
Wattage
22-30 W
Lumen output
3520-4800 lm
LED
220 - 240V AC, 50/60Hz
20
II
ce
True

Light distributions

product.polar.curve.image,90
Default

Options

Product code
Power consumption[W]
0 0
Lumen output[lm]
0 0
CCT
CRI
Dimming
SQEA-L-830-1
30.0
4800
3000k
80
Non-dimmable
Power consumption[W]30.0
Lumen output[lm]4800
CCT3000k
CRI80
DimmingNon-dimmable
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-L-830-2
30.0
4800
3000k
80
DALI
Power consumption[W]30.0
Lumen output[lm]4800
CCT3000k
CRI80
DimmingDALI
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-L-840-1
30.0
4800
4000k
80
Non-dimmable
Power consumption[W]30.0
Lumen output[lm]4800
CCT4000k
CRI80
DimmingNon-dimmable
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-L-840-2
30.0
4800
4000k
80
DALI
Power consumption[W]30.0
Lumen output[lm]4800
CCT4000k
CRI80
DimmingDALI
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-M-830-1
26.0
4160
3000k
80
Non-dimmable
Power consumption[W]26.0
Lumen output[lm]4160
CCT3000k
CRI80
DimmingNon-dimmable
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-M-830-2
26.0
4160
3000k
80
DALI
Power consumption[W]26.0
Lumen output[lm]4160
CCT3000k
CRI80
DimmingDALI
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-M-840-1
26.0
4160
4000k
80
Non-dimmable
Power consumption[W]26.0
Lumen output[lm]4160
CCT4000k
CRI80
DimmingNon-dimmable
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-M-840-2
26.0
4160
4000k
80
DALI
Power consumption[W]26.0
Lumen output[lm]4160
CCT4000k
CRI80
DimmingDALI
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-S-830-1
22.0
3520
3000k
80
Non-dimmable
Power consumption[W]22.0
Lumen output[lm]3520
CCT3000k
CRI80
DimmingNon-dimmable
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-S-830-2
22.0
3520
3000k
80
DALI
Power consumption[W]22.0
Lumen output[lm]3520
CCT3000k
CRI80
DimmingDALI
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-S-840-1
22.0
3520
4000k
80
Non-dimmable
Power consumption[W]22.0
Lumen output[lm]3520
CCT4000k
CRI80
DimmingNon-dimmable
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →
SQEA-S-840-2
22.0
3520
4000k
80
DALI
Power consumption[W]22.0
Lumen output[lm]3520
CCT4000k
CRI80
DimmingDALI
↓ DatasheetPDF → ↓ LDT súborLDT → Zobraziť detail →

Downloads

↓ Datasheet PDF → ↓ CE PDF → ↓ Manual PDF →

Used in projects

Industry Slovak parcel Lužianky Slovakia

Slovak parcel Lužianky

Zobraziť projekt → Office Calsonic Marelli Slovakia

Calsonic Marelli

Zobraziť projekt → Retail Shopping center Nitra Slovakia

Shopping center Nitra

Zobraziť projekt → Office IT-impulse Slovakia

IT-impulse

Zobraziť projekt → Industry Hainbuch Slovakia

Hainbuch

Zobraziť projekt → Industry Linde Slovakia

Linde

Zobraziť projekt → Industry Garbe Slovakia

Garbe

Zobraziť projekt →

Alternatives

Square easy

Square easy

https://www.arlistore.com/web/image/product.template/57/image_1920?unique=abc402e
44.93 € 44.93 €
